Custom made Turnkey PCB assembly Fast Delivery control board for electric fireplace
Shinelink company is a Manufacturer and Supplier Specializing in Double Side PCB, Multi-Layer PCB, PTFE PCB, Ceramic PCB, Rogers PCB, Aluminium PCB, Flexible PCB with more than 10 years. Meanwhile, we provide PCBA ( Assembly) and ODM, OEM service. We are specializes in a full SMT and through hole PCBA assembly, obtaining components, building prototype quantities, and testing.
Quote requirement
1. Gerber file of the bare PCB board
2. BOM (bill of material) for assembly
3. To short the lead time, please kindly advise us if there is any acceptable components substitution
4. Testing guide and test fixtures if necessary
5. Programming files and programming tool if necessary
6. Schematic if necessary
Our Production Capability for PCB
| Number of Layer | 1 - 20 Layer |
| Maximum Processing Area | 680 × 1000MM |
| Min Board Thickness | 2 Layer - 0.3MM ( 12 mil ) |
| 4 Layer - 0.4MM ( 16 mil ) | |
| 6 Layer - 0.8MM ( 32 mil ) | |
| 8 Layer - 1.0MM ( 40 mil) | |
| 10 Layer - 1.1MM ( 44 mil ) | |
| 12 Layer - 1.3MM ( 52 mil ) | |
| 14 Layer - 1.5MM ( 59 mil ) | |
| 16 Layer - 1.6MM ( 63 mil ) | |
| 18 Layer - 1.8MM ( 71 mil ) | |
| Finished Board Thickness Tolerance | Thickness ≤ 1.0MM, Tolerance: ± 0.1MM |
| 1.0MM ≤ Thickness ≤ 6.5MM, Tolerance ± 10% | |
| Twisting and Bending | ≤ 0.75%, Min: 0.5% |
| Range of TG | 130 - 215 ℃ |
| Impedance Tolerance | ± 10%, Min: ± 5% |
| Hi-Pot Test | Max: 4000V/10MA/60S |
| Surface Treatment | HASL, With Lead, HASL Free Lead |
| Flash Gold, Immersion Gold | |
| Immersion Silver, Immersion Tin | |
| Gold Finger, OSP |
Shinelink kinds PCBA Products
Our PCBA Capability
SMT, PTH, mixed technology
SMT: 2,000,000 solder joints per day
DIP: 300,000 joints per day
Ultra fine pitch, QFP, BGA, μBGA, CBGA
Advanced SMT assembly
Automated insertion of PTH (axial, radial, dip)
Cleanable, aqueous and lead-free processing
RF manufacturing expertise
Peripheral process capabilities
Pressfit back planes & mid planes
Device programming
Automated conformal coating
For E-Test
Universal Tester
Flying Probe Open/Short Tester
High power Microscope
Solder ability Testing Kit
Peel Strength tester
High Volt Open & Short tester
Cross Section Molding Kit With Polisher
| If you need PCB assembly service as well, could you give us following information? | |
| 1. | Gerber file of the bare PCB board |
| 2. | BOM(Bill of material) for assembly |
| To short the Lead time, please kindly advise us if there is any acceptable components substitution. | |
| 3. | Testing Guide & Test Fixtures, if necessary |
| 4. | Programming files & Programming tool, is necessary |
| 5. | Schematic, if necessary |
Our products are sold all over the world, you can rest assured.
