Lead free single sided pcb layout FR4 material with 1OZ copper

Lead free single sided pcb layout FR4 material with 1OZ copper

  • High Light

    single sided printed circuit board

    ,

    single layer printed circuit board

  • Surface Finish
    Lead Free FR4
  • Layer
    1 Layer
  • Material
    FR4
  • Feature
    100% E-test
  • Max. Layer-up
    20 Layers
  • Max. Unit Size
    620*813mm
  • Place of Origin
    China
  • Brand Name
    OEM/ODM
  • Certification
    UL,RoHS, CE
  • Model Number
    SL71207L022
  • Minimum Order Quantity
    1pc
  • Price
    Negotiable
  • Packaging Details
    ESD package
  • Delivery Time
    5-7 days
  • Payment Terms
    T/T, Western Union, MoneyGram,Paypal
  • Supply Ability
    1000pcs per day

Lead free single sided pcb layout FR4 material with 1OZ copper

Lead free single sided pcb layout FR4 material with 1OZ copper





PCB capability



Layer, 1 Layer

Material, FR4, RoHS compliance

PCB Thickness, 1.6mm+/-10%

E-Test, 100%
Outgoing Reports, Final Inspection Report, E-Test Report, Solderability Test Report, Microsection Report and so on.
Inspection Standard, IPC-A-600H/IPC-6012B Class2 and IPC-A-600H/IPC-6012B class3

Certificates, UL, RoHS, ISO



Our Pcba service include



1. PCB board file with parts list provided by customers

2. PCB board made, circuit board parts purchased by us

3. PCB board with parts assembled

4. Electronic testing circuit board or PCBA

5. Fast delivery, anti-static package

6. RoHS Directive-compliant, lead-free

7. One stop service for PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery



PCB Capabilities



Number of Layer 1 - 20 Layer
Maximum Processing Area 680 × 1000MM
Min Board Thickness 2 Layer - 0.3MM ( 12 mil )
  4 Layer - 0.4MM ( 16 mil )
  6 Layer - 0.8MM ( 32 mil )
  8 Layer - 1.0MM ( 40 mil)
  10 Layer - 1.1MM ( 44 mil )
  12 Layer - 1.3MM ( 52 mil )
  14 Layer - 1.5MM ( 59 mil )
  16 Layer - 1.6MM ( 63 mil )
  18 Layer - 1.8MM ( 71 mil )
Finished Board Thickness Tolerance Thickness ≤ 1.0MM, Tolerance: ± 0.1MM
  1.0MM ≤ Thickness ≤ 6.5MM, Tolerance ± 10%
Twisting and Bending ≤ 0.75%, Min: 0.5%
Range of TG 130 - 215 ℃
Impedance Tolerance ± 10%, Min: ± 5%
Hi-Pot Test Max: 4000V/10MA/60S
Surface Treatment HASL, With Lead, HASL Free Lead
  Flash Gold, Immersion Gold
  Immersion Silver, Immersion Tin
  Gold Finger, OSP





FAQ



1. What service can you provide?



We can provide PCB circuit board gerber file design,Copy and Clone,OEM and ODM service.Not only produce PCB,PCB Assembly,but also Mold making ,Plastic Injection,and Complete products



2. Are my design files secure when I send them to you?



Your files are held in complete safety and security while Shinelink Technology Ltd is in possession of them. Your files are never shared nor will any third parties have access to your design files. Since they are your property, we respect the copyright of your files. The customer controls the disposition of these files per your requirements and written approval.



3. For small quantity orders, can you produce prototype PCBs?



Yes. Shinelink Technology Ltd has the capability to produce circuit boards in any amount. But,the greater the quantity, the greater the cost savings.



4. Do you have an order minimum?



We don't have MOQ, accept order with as low as a quantity of 1 (piece or panel).



5. What file formats do you accept for PCB assembly?



Gerber and CAM Auto CAD DXF, DWG formats.





Advantage



1. ISO& UL certified third-party testing and high-quality technical service team.

2. Available and immediate delivery.

3. Producing capacity: 20,000sq meter/month.

4. Competitive price with no MOQ.





About us



Shinelink Technology Ltd is more than just a leading PCB manufacturer. We are capable of providing all PCB assembly needs inculding full turnkey and partial turnkey printed circuit board assembly services.



For full turn-key, we take care of the entire process, including preparation of Printed Circuit Boards, procurement of components, online order tracking, continuous monitoring of quality and final assembly. Whereas for partial turn-key, the customer can provide the PCBs and certain components, and the remaining parts will be handled by us.



We has modernized its PCB assembly services to offer a one-stop, turn-key PCB assembly service which includes parts, fabrication and assembly - reducing production costs while improving quality and convenience.
