Quick-turn pcb prototype for pcb fabrication with low volume pcb

Quick-turn pcb prototype for pcb fabrication with low volume pcb

  • High Light

    electronics prototyping board

    ,

    prototype printed circuit board

  • Certificate
    UL, RoHS
  • Min.hole Size
    0.2mm
  • Board Thicknss
    1.6mm
  • Copper Thicknss
    1.0OZ
  • Features 1
    100% E-test
  • Features 2
    Gerber/PCB File Needed
  • Place of Origin
    China
  • Brand Name
    OEM/ODM
  • Certification
    UL,RoHS, CE
  • Model Number
    SL71206L022
  • Minimum Order Quantity
    1pc
  • Price
    Negotiable
  • Packaging Details
    ESD package
  • Delivery Time
    5-7 days
  • Payment Terms
    T/T, Western Union, MoneyGram,Paypal
  • Supply Ability
    1000pcs per day

Quick-turn pcb prototype for pcb fabrication with low volume pcb

Quick-turn pcb prototype for pcb fabrication with low volume pcb





Layer, 2Layer

Material, FR4, RoHS compliance

PCB Thickness, 1.6mm+/-10%

E-Test, 100%
Outgoing Reports, Final Inspection Report, E-Test Report, Solderability Test Report, Microsection Report and so on.
Inspection Standard, IPC-A-600H/IPC-6012B Class2 and IPC-A-600H/IPC-6012B class3

Certificates, UL, RoHS, ISO


PCB Capabilities



Number of Layer 1 - 20 Layer
Maximum Processing Area 680 × 1000MM
Min Board Thickness 2 Layer - 0.3MM ( 12 mil )
  4 Layer - 0.4MM ( 16 mil )
  6 Layer - 0.8MM ( 32 mil )
  8 Layer - 1.0MM ( 40 mil)
  10 Layer - 1.1MM ( 44 mil )
  12 Layer - 1.3MM ( 52 mil )
  14 Layer - 1.5MM ( 59 mil )
  16 Layer - 1.6MM ( 63 mil )
  18 Layer - 1.8MM ( 71 mil )
Finished Board Thickness Tolerance Thickness ≤ 1.0MM, Tolerance: ± 0.1MM
  1.0MM ≤ Thickness ≤ 6.5MM, Tolerance ± 10%
Twisting and Bending ≤ 0.75%, Min: 0.5%
Range of TG 130 - 215 ℃
Impedance Tolerance ± 10%, Min: ± 5%
Hi-Pot Test Max: 4000V/10MA/60S
Surface Treatment HASL, With Lead, HASL Free Lead
  Flash Gold, Immersion Gold
  Immersion Silver, Immersion Tin
  Gold Finger, OSP





Advantage



1. ISO& UL certified third-party testing and high-quality technical service team.

2. Available and immediate delivery.

3. Producing capacity: 20,000sq meter/month.

4. Competitive price with no MOQ.
