Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device

Good quality Turnkey PCB Assembly for sales
Good quality Turnkey PCB Assembly for sales
very nice service, price is competitive and reasonable, delivery is fast and on time, I like working with your company.

—— Ali

you guys offer very good quality product and quick response on quotes, I am very happy and satisfied. thanks for all your support.

—— David

Good quality with best service, Good job, Sandy !

—— Dan

So appreciate to Sandy, very fast delivery, good quality. I will order from you next month.

—— Sam

I'm Online Chat Now

Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device

China Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device supplier
Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device supplier Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device supplier

Large Image :  Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device

Product Details:

Place of Origin: China
Brand Name: OEM and ODM
Certification: UL,ROhs
Model Number: SL81028S012

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD2.2-5/PC
Packaging Details: ESD Bag
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union, MoneyGram,Paypal
Supply Ability: 10000pcs per day
Contact Now
Detailed Product Description
Surface Finishing: HASL Product Name: PCBA Electronic
Type: EMS Feature 1: Gerber File Needed
Feature 2: 100% E-test Feature 3: Quality 2 Years Guarantee

Costomized Electronic PCB PCBA for GPS tracker GPS module device




Article

Description

Capability

Sercive

PCB and SMT assembly with one-stop service

Material

Laminate materials

FR4, high TG FR4, high frequency, alum, FPC

Board cutting

Number of layers

1-48

Min.thickness for inner layers

(Cu thickness are excluded)

0.003”(0.07mm)

Board thickness

Standard

(0.1-4mm±10%)

Min.

Single/Double:0.008±0.004”

4layer:0.01±0.008”

8layer:0.01±0.008”

Bow and twist

7/1000

Copper weight

Outer Cu weight

0.5-4 0z

Inner Cu weight

0.5-3 0z

Drilling

Min size

0.0078”(0.2mm)

Drill deviation

±0.002″(0.05mm)

PTH hole tolerance

±0.002″(0.005mm)

NPTH hole tolerance

±0.002″(0.005mm)

Solder mask



Color

Green,white,black,red,blue…

Min solder mask clearanace

0.003″(0.07mm)

Thickness

(0.012*0.017mm)

Silkscreen

Color

white,black,yellow,blue…

Min size

0.006″(0.15mm)

E-test

Function Test

100% Functional test

PCBA Testing

X-ray,AOI Test,Functional test

Pcb assembly

one-stop service electronic manufacxturer service

Component sourcing

Yes

Certificate

IATF16949,ISO9001

Delivery time:

PCB

3-12days

PCBA

8-20days

Tolerance of pcb

±5%

Max size of finish board

450*450mm

MOQ

NO MOQ (1pcs)

Surface Finish

HASL,ENIG,immersion silver,immersion tin,OSP…

PCB outline

Square,circle,irregular(with jigs)

package

QFN,BGA,SSOP,PLCC,LGA

Sub-assembly

Plastic,metal,screen





OEM/ODM/EMS Services For PCBA



· PCBA, PCB Board assembly: SMT & PTH & BGA

· PCBA and enclosure design

· Components sourcing and purchasing

· Quick prototyping

· Plastic injection molding

· Metal sheet stamping

· Final assembly

· Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)

· Custom clearance for material importing and product exporting





PCB Manufacturing Lead Time



Layer/Days Sample(Normal) Sample(Fast) Mass Production
Single/Double 2-3days 24hours 5-7days
Four Layer 7-10days 3days 7-10days
Six Layer 7-10days 5days 13-15days
Eight Layer 15-20days 7days 15-20days




PCB Assembly Capabilities



Turnkey PCBA PCB+components sourcing+assembly+package
Assembly details SMT and Thru-hole, ISO lines
Lead Time Prototype: 15 work days. Mass order: 20~25 work days
Testing on products Flying Probe Test, X-ray Inspection, AOI Test, functional test
Quantity Min quantity: 1pcs. Prototype, small order, mass order, all OK
Files we need PCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB panel Size Min size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder Type Water Soluble Solder Paste, RoHS lead free
Components details Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package Cut Tape,Tube,Reels,Loose Parts
PCB assembly
process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing





PCBA Picture



Costomized Electronic PCB Assembly HASL Surface For GPS Tracker GPS Module Device
