FCCL 105um Copper ENIG Flexible Printed Circuit Board

FCCL 105um Copper ENIG Flexible Printed Circuit Board

  • High Light

    ENIG Flexible Printed Circuit Board

    ,

    FCCL Flexible Printed Circuit Board

    ,

    105um Copper Flexible PCBs Board

  • Soldermask
    Yellow
  • Material
    Rolled Anneal Copper FCCL
  • Certificate
    RoHS
  • Min.Lin Width
    0.075mm
  • Feature 1
    Gerber File Needed
  • Feature 2
    100% E-test
  • Place of Origin
    China
  • Brand Name
    No
  • Certification
    UL, ROhs
  • Model Number
    SL01118S08
  • Minimum Order Quantity
    1pc
  • Price
    Negotiation
  • Packaging Details
    ESD Bag
  • Delivery Time
    5-7 days
  • Payment Terms
    T/T, Western Union, MoneyGram,Paypal
  • Supply Ability
    10000 Piece/Pieces per Day

FCCL 105um Copper ENIG Flexible Printed Circuit Board

Flexible printed circuits Automobile Medical Precision Square Circle Flexible PCBs





SHINELINK Company survival over 20 years, as our goal is always provide best quality pcba solution for customers from domestic and abroad like Japan, Brazil, America, Russia, Gemany, France, UK etc. FASTPCBA can turn your pcb design to pcba or pcb assp, welcome to inquiry and visit us in shenzhen china.





Flexible Printed Circuit Board (abbr. FPCB) .



FPCB is minimization, slimness, high technology for whole digital products which are getting smaller, slimmer.

Compare with the rigid printed circuit board , FPCB has the following advantages



1. Light, thin, short, small, flexible structure, can be bent, curled, folded, and three-dimensional assembly, adapter can replace a lot of parts, easy to use maximum available space, making electronic products become more slim in appearance, widely used has a small, lightweight and mobile requirements of all kinds of electronic products.



2. High heat resistance, can produce higher density and finer pitch products to meet the high density interconnect between the components and the high stability requirements, so that a larger increase the quality of the signal output.



3. Can be wound transfer roller processing methods (Roll-to-Roll), easily automated, mass production,improve production efficiency.





FPC Process Capability



Items FPC Process Capability
Number of Layers Single Sided, Double Sided, Multilayer, Rigid-flex PCB
Based Material PI, PET
Copper Thickness 9um,12um,18um,35um,70um,105um
Largest Board Area 406mm X 610mm/16"X 24",The largest could be 7 meters length in Single sided Flexible Printed Circuit Board
Minimum Hole Diameter of Mechanical Drilling 0.2mm/0.008"
Minimum Hole Diameter of Laser Drilling 0.075mm/0.03"
Minimum Hole Diameter of Hole-punching 0.50mm/0.02"
Tolerance of Plated Through Hole +/-0.05mm/±0.02"
Minimum Line Width 0.075mm/0.003"
Minimum Line Spacing 0.075mm/0.003"
Peel Strength 1.2kg f/cm
Shape Processing Die Stamping, Cutting, Laser Prototyping
Appearance of Tolerance +/-0.05mm/ +/-0.02"
Solder Mask Type

PI Solder Mask Coverlay Film or PET Solder Mask Covelay Film Lamination





Multi-colored Liquid Photo-Imageable solder Mask Ink, Thermosetting Solder Mask Ink
Surface Treatment Plating Tin, Immersion Tin, Plating Nickel Gold, ENIG (Electroless Nickel Immersion Gold),Immersion Nickel Gold, Chemical Nickel Gold,OSP (Organic Solderability Preservatives), Immersion Silver






Application For Whole Digital Products
